ASTM Molds, Test Cylinder Molds, Pellet Press and other
Dies Listing


Stick Mold	Picture Frame Mold	Tile Mold	Color Dispersion Disc Mold
Made of stainless steel or hardened tool steel. For ceramic, metal and other powder or granules. Stick molds are designed and built to specific customer requirements.	Made of stainless steel or hardened tool steel. Can be used for powders, ceramics and plastics. Minimum size 1¼ x 1¼.	Plated steel or stainless steel frame with polished steel top and bottom covers. Can be used up to 400°F to form plastic or rubber sheets. Use with Carver heated, or heated and cooled platens.	For making plastic film to check color dispersion or clarity. Provides precise film thickness and parallelism. Made of stainless steel or hardened tool steel. Includes die, upper punch and lower punch. Spacers available for optional film thickness.

Catalog Number	Description	Sample Dimensions	Sample Thickness	Material	Max. Clamping Force
818701D	Tile Mold	50mm x 50mm	1mm, 2mm, 5mm	440 Stainless Steel	N/A
818702D	Tile Mold	100mm x 100mm	1mm, 2mm, 5mm	440 Stainless Steel	N/A
818703D	Tile Mold	150mm x 150mm	1mm, 2mm, 5mm	440 Stainless Steel	N/A
818704C	Color Dispersion	50mm diameter	0.1mm, 0.2mm, 0.5mm	440 Stainless Steel	N/A
818705D	Color Dispersion	100mm diameter	0.1mm, 0.2mm, 0.5mm	440 Stainless Steel	N/A
818697D	Picture Frame	10" x 10"	1mm, 2mm, 5mm	440 Stainless Steel	N/A
818698D	Tile Mold	4" x 4"	1mm, 2mm, 5mm	440 Stainless Steel	N/A
818699D	Tile Mold	6" x 6"	1mm, 2mm, 5mm	440 Stainless Steel	N/A
818700D	Tile Mold	10" X 10"	1mm, 2mm, 5mm	440 Stainless Steel

Laboratory Press Test Cylinder, Heated Text Cylinders, ASTM Molds, Pellet Dies and Molds Accessories Listing

Test Cylinder and Pellet Dies
2090	Test cylinder outfit, 1.125" I.D.
2090.1	Set of 12 filter pads for 2090
2091	Test cylinder outfit, 2.25" ID
2091.1	Set of 12 filter pads for 2091
237005	Stainless steel pan for either
2091.2	Test cylinder outfit all stainless steel, 2.25" ID
2092	Swivel bearing plate (requires safety shield)
2095	KBr buffer plate
4417	6mm pellet die, 440 stainless steel
4946	12mm pellet die, 440 stainless steel
3619	13mm pellet die, 440 stainless steel
4369	25mm pellet die, 440 stainless steel
3902	31mm pellet die, 440 stainless steel
3876	40mm pellet die, 440 stainless steel

Heated Test Cylinders
2472	Heating jacket with 1.125" test cylinder
2417	Heating jacket with 2.25" test cylinder

ASTM Molds
Catalog Number	Description	Sample Dimensions	Sample Thickness	Material	Max. Clamping Force
4074	Chase Assembly	4" x 4"	N/A	Teflon	N/A
4080	Chase Assembly	4" x 4"	N/A	Stainless Steel	N/A
4081	Chase Assembly	4" x 4"	N/A	Brass	N/A
4082	Chase Assembly	6" x 6"	N/A	Teflon	N/A
4083	Chase Assembly	6" x 6"	N/A	Stainless Steel	N/A
4084	Chase Assembly	6" x 6"	N/A	Brass	N/A
4085	Chase Assembly	8" x 8"	N/A	Teflon	N/A
4086	Chase Assembly	8" x 8"	N/A	Stainless Steel	N/A
4087	Chase Assembly	8" x 8"	N/A	Brass	N/A
4161	(100) Mylar Sheets for 4" x 4" Molds	6" x 6"	N/A	N/A	N/A
4162	(100) Mylar Sheets for 6" x 6" Molds	8" x 8"	N/A	N/A	N/A
4163	(100) Mylar Sheets for 8" x 8" Molds	10" x 10"	N/A	N/A	N/A
818744C	Pharmaceutical pellet die holder

Vacuum Pump Kit
3874	Used with pellet press to evacuate molds or dies
